MIL-DTL-38999 Connector Accessories
MIL-DTL-38999 connector accessories are used for shielded cable and shielding braid termination. They are available in straight and 90-degree elbow types. When the connector accessories are paired with a titanium-nickel ring, they provide 360-degree EMI and RFI shielding protection.
Specifications
| Mating Compatibility | MIL-DTL-38999 Series I/II/III/IV |
| Shell Size | 9 to 25 |
| Wire Accommodation | 0.1 to 10 mm² (Multi-core / Shielded / Unshielded) |
| EMI Shielding | 100 MHz to 10 GHz: ≥ 60 dB |
| Operating Temperature | -65 °C to +200 °C |
| Ingress Protection | IP67 / IP68 |
| Salt Spray | 48 to 1,000 h (depending on coating class) |
| Mating Cycles | 500 cycles |
| Vibration | 10 to 2000 Hz, 294 m/s² |
| Mechanical Shock | 300 g, 3 ms, half-sine wave |
| Cable Retention Force | Size 22D to 10: 45 N to 111 N |
| Shell Material | Aluminum Alloy, Stainless Steel, Copper Alloy |
| Plating | Olive Drab Cadmium, Electroless Nickel, Passivated |
| Seal Material | Silicone / Fluorosilicone Rubber |
| Coupling | Threaded / Bayonet / Crimp |
Features
- The accessories are compatible with MIL-DTL-38999 I/II/III/IV connectors, for a wide range of shell sizes, mounting options, and cable types
- Designed for harsh environments with IP67/IP68 protection, including resistance to salt spray, humidity, and extreme temperatures.
- Their EMI shielding is achieved through all-metal or shielded construction with continuous grounding to the connector housing for stable signal performance.
- Feature high mechanical strength to ensure resistance to vibration, shock, and cable pull-out for long-term reliability in demanding applications.
- Quick-lock and threaded designs support fast assembly without soldering and allow easy field maintenance and replacement.
- They have a corrosion-resistant design made of aluminum alloy or stainless steel with military-grade plating, for protection against oil, solvents, and fungal exposure.
