ARINC801 Fiber Optic Connectors
These circular fiber optic connectors comply with the interface dimensions of the GJB599B (MIL-DTL-38999) Series III standard and meet ARINC801 requirements. They are suitable for multi-channel optical communication applications in aerospace, electronics, and naval systems, thanks to their precise alignment, simple maintenance, and stable high-reliability signal transmission.
Specifications
| Insertion Loss | ≤ 0.6 dB |
| Return Loss | Single-mode (SM): ≥ 30 dB Multi-mode (MM): ≥ 20 dB |
| Mating cycles | 500 cycles |
| Vibration | 10 to 2000 Hz, 0.4 g²/Hz PSD, 23.1 g RMS |
| Mechanical Shock | 2940 m/s², 3 ms duration, ΔV = 5.61 m/s |
| Operating Temperature | -55 °C to +125 °C (Upper limit depends on cable rating) |
| Air Leakage Rate | ≤ 1 × 10⁻⁹ Pa·m³/s at 1 atm differential |
| Salt Spray | Class K: 500 hours Class F: 48 hours Class W: 500 hours Class MW: 192 hours (SO₂ / Acidic) |
| Cable Retention Force | ≥ 68 N (for 2.0 mm contacts/jumpers) |
| Radiation Resistant | Available |
Features
- Circular fiber optic connectors have standard 1.25 mm ceramic ferrules to ensure precise mating performance.
- Designed with a ceramic sleeve array that allows full removal and replacement for easier maintenance.
- Compatible with dedicated installation and removal tool M81969/14-03 for simple and efficient operation.
